Keyvex™ 7200
Keyvex™ 7200 is a hydrofluoroether (HFE) engineered fluid designed for heat transfer, precision cleaning and vapor degreasing applications. Developed as a direct replacement for 3M™ Novec™ 7200, it can also provide an alternative to other conventional fluorinated heat-transfer and cooling fluids. Its applications include data center immersion cooling, electronics and semiconductor cooling, power electronics heat transfer, and specialized industrial heat-transfer processes.
Applications:
Heat Transfer
Precision Cleaning
Vapor Degreasing
Carrier Solvent
- Heat transfer fluid for electrical and electronic applications
- Effective for removing particulates, light oils, and fluoropolymers.
- Carrier solvent for deposition and coating processes
- Specialty solvents, dispersion medium, reaction medium, extraction solvent
- Excellent dielectric properties.
- Higher boiling point than many traditional CFC, HCFC, and HFC solvents, helping reduce fluid loss during operation.
- Low surface tension allows it to penetrate tight spaces for thorough cleaning.
- Non-flammable.
- Non-conductive enables direct-contact cooling of energized electronic components without electrical conductivity concerns.
Property
Value
Appearance
Colorless, transparent liquid
Density (25°C).g/mL
1.432
Boiling Point, °C
76
Freezing Point, °C
-138
KB Value
3.57
Kinematic Viscosity (25°C), mm2/s
0.4832
Vapor Pressure (25°C), mmHg
108.76
Surface Tension (25°C), dynes/cm
14.2
Dielectric Strength (2.5 mm), KV
≥ 29.9
Metals: Aluminum, Anodized Aluminum, Stainless Steel, Carbon Steel, Copper, Brass, Bronze, Nickel, Titanium
Plastics: PTFE, PFA, FEP, ETFE, PVDF, PEEK, PPS, Polypropylene (PP), Polyethylene (HDPE), Acetal (POM)
Elastomers: FKM (Viton®), FFKM, EPDM, Silicone (VMQ), Fluorosilicone (FVMQ), NBR
Ceramics & glass: Alumina, Zirconia, Quartz, Borosilicate Glass, Soda-Lime Glass, Glass Ceramics
Related Products:
Let’s Find the Right Solution for Your Process
Our technical team can help identify the appropriate Keyvex equivalent based on your current fluid, application, and performance requirements.
